708-2L-00300 HPV95 Main Pump for Komatsu PC200-7
708-2L-00300 is a complete main-pump entry for Komatsu PC200-7. The HPV95 tandem pump has two pumping sections serving the excavator hydraulics. A pump purchase identifies the whole assembly and its regulator; a workshop rotating-group rebuild is a separate parts order. Keep the PC200-7 machine generation on the line rather than combining all PC200 pumps under one number.
- Model / Part No.
- 708-2L-00300
- Component / application
- Komatsu PC200-7 · HPV95
- Assembly part number
- 708-2L-00300
- Pump family
- HPV95
- Arrangement
- Tandem double pump
708-2L-00300 Specifications
| Model / part number | 708-2L-00300 |
|---|---|
| Assembly part number | 708-2L-00300 |
| Machine generation | Komatsu PC200-7 |
| Pump family | HPV95 |
| Arrangement | Tandem double pump |
| Task | Main hydraulic pump |
| Sales unit | Pump assembly |
Three PC200 generations use separate pump lines
The PC200 model name extends across several hydraulic-system generations. The three assembly numbers below are distinct purchase entries.
| Machine generation | Pump assembly | Purchase type |
|---|---|---|
| PC200-6 | 708-2L-00461 | Complete HPV95 main pump |
| PC200-7 | 708-2L-00300 | Complete HPV95 main pump |
| PC200-8 | 708-2L-00490 | Complete main-pump assembly |
The regulator and ports belong with the assembled pump
The engine-side spline and flange mount the pump mechanically. Suction, the two delivery circuits, case drain and regulator connections identify the hydraulic installation. Keep the mounting view and control arrangement beside the machine serial.
Complete pump or rotating-group rebuild?
A complete assembly replaces the pump and selected controls. A rebuild keeps the original housings and renews internal components such as pistons, cylinder blocks, valve plates and seals. The rebuild list uses the original pump number and the workshop’s dismantled component measurements.
A hydraulic repair order can contain filters and seals
List pump-to-pipe seals and the machine’s hydraulic filters separately from the pump. If wear debris from an old pump is present, the workshop’s cleaning and hydraulic service work belongs with the replacement job.
Compare excavator hydraulic main pumps & components
| Product | Machine | Pump format | Control configuration | Shipping package |
|---|---|---|---|---|
| K3V112DT-9C32 | Hyundai R210LC-7 | DT: tandem double pump | 9C32 configuration | 70 × 30 × 30 cm · 150 kg gross |
| K3V112DTP-0E11 | Sany SY205 / SY215 | DTP: tandem with PTO | 0E11 electronic control | 60 × 30 × 30 cm · 150 kg gross |
Purchase Options & Service Parts
Purchase options
- Complete main-pump assembly
- New replacement / rebuilt assembly on separate offers
- Regulator and pilot / gear-pump arrangement
- Installation seals and hydraulic-filter repair list
Service & replacement parts
- Pistons / shoes and cylinder blocks
- Valve plates
- Shaft seal and O-rings
- Regulator parts
- Hydraulic service filters
708-2L-00300 Buying Questions
Is the machine generation part of the pump identity?
Yes. This purchase is for PC200-7 and part number 708-2L-00300. The PC200-6, PC200-7 and PC200-8 pump entries have separate assembly numbers and connection arrangements.
Can I order a complete pump and repair parts together?
Yes. Keep the assembled pump on one line and rotating-group or regulator rebuild parts on their own lines. Each purchase belongs to its complete pump identity.
Which components distinguish new and rebuilt offers?
The supplied condition, assembled regulator, input drive, ports and hydraulic test record belong on each offer. A rebuilt original assembly and a new replacement have separate product identities.
What else belongs in a pump replacement order?
Installation seals, hydraulic service filters and any gear-pump or regulator items can be included as separately identified repair lines.
