Excavator Compaction Wheels
SC Equipment SC12 Mechanical Compaction Wheel
A 640 kg mechanical wheel for 10–15 tonne excavators, with 840 mm wheel diameter, 400 mm working width and 24 pads.
- Model / Part No.
- SC Equipment SC12
- Machine / configuration
- 10–15 tonne excavators
- Wheel diameter
- 840 mm
- Compaction width
- 400 mm
- Overall width
- 595 mm
SC Equipment SC12 Specifications
| Model / part number | SC Equipment SC12 |
|---|---|
| Carrier | 10–15 t |
| Wheel diameter | 840 mm |
| Compaction width | 400 mm |
| Overall width | 595 mm |
| Overall height | 935 mm |
| Pad count | 24 |
| Weight | 640 kg |
| Drive | Mechanical, no attachment motor |
Distinguish work width and access width
The 400 mm working width and 595 mm overall envelope have different jobs in the trench drawing.
Specify the mechanical mount
The carrier connection is pin-mounted or a coupler pickup selected in the order drawing. No attachment drive circuit is needed.
Use the SC12 dimension drawing to plan trench access
| Field | SC12 figure | Use |
|---|---|---|
| Wheel diameter | 840 mm | Rolling envelope |
| Compaction width | 400 mm | Pad-working strip |
| Overall width | 595 mm | Clear access |
| Overall height | 935 mm | Mount and working outline |
| Pads / mass | 24 / 640 kg | Working assembly and carrier load |
The carrier supplies the mechanical movement
The wheel rolls its pads through placed fill as the excavator applies the working movement. The mounting pins, wheel axle, bearings/seals and pad arrangement are mechanical assemblies; the wheel has no attachment-drive hydraulic motor. Add the selected pad/axle service group to the mounting purchase.
Purchase Options & Service Parts
Purchase options
- SC12 wheel/pad assembly
- Machine-specific pin mounting
- Selected bearing/seal package
- Spare pad and mounting parts
Service & replacement parts
- Pads
- Wheel bearings and seals
- Axle assembly
- Mounting pins and bushes
SC Equipment SC12 Buying Questions
How many pads are listed?
24.
What is the attachment weight?
640 kg.
Which width belongs on the access drawing?
595 mm is the overall width. The separate 400 mm entry describes the compaction strip.
What is in the axle-service group?
The wheel axle, bearings and seals are distinct from the excavator mounting pins and bushes.
