McLaren Maximizer 30X822X56 Over-Tire Tracks —Bobcat S650 Set
Two steel over-tire tracks with 12-inch pads for the named Bobcat S650 tyre-wrapping installation.
McLaren Maximizer 30X822X56
PRODUCT CATEGORY
Skid Steer Over-Tire Tracks
Compare a two-track S650 conversion set, tyre/frame clearance and separately numbered pad/link repair parts.
1 products
Models and component numbers
No matching products.
Send the part number or describe the equipment you need.
Send a sourcing requestStart with the two-track conversion set
McLaren Maximizer 30X822X56 is the named S650 set with 12-inch steel pads. A product unit is two tracks. The fitted tyres and wheel position define the installation around which the tracks wrap.
| Product | Named machine | Pad size | Purchase unit |
|---|---|---|---|
| McLaren Maximizer 30X822X56 | Bobcat S650 | 12 in steel pad | Two-track set |
The tyre and frame clearance define the spacer purchase
Measure tyre width and outside diameter, wheelbase, tyre-to-frame gap and clearance to the lift structure. Record the wheel bolt pattern and offset with any spacer thickness. The spacer and its fixing hardware are separate from the steel track set.
Loegering Link, Bushing and Spacer Parts
Loegering F-Series FN103-11.1A is the 10.00×16.5 pad entry with 11⅛-inch dimension A. FN103-12.5A is the 12.00×16.5 pad entry with 12½-inch dimension A. Their links and pins also have separate standard/heavy configurations.
| Part | Number | Configuration |
|---|---|---|
| 10.00×16.5 pad | FN103-11.1A | Dimension A 11⅛ in |
| 12.00×16.5 pad | FN103-12.5A | Dimension A 12½ in |
| Standard 3-hole link | FN425 | ½ in thick |
| Heavy3-hole link | FN424 | ⅝ in thick |
| Standard Dura pin | 400660 | ⅝×1½ in |
| Heavy Dura pin | 400670 | ⅝×1⅝ in |
| Jam nut | PH0171-5CP | ½-20 UNF Grade 8 nyloc |
Use the installed track system for the spare-parts order
The Loegering pad and link numbers belong to its F-Series system. The McLaren Maximizer uses its own selected pad/link arrangement. Count damaged pads, links, pins and nuts against the installed manufacturer/model when building a replenishment shipment.
